Model

SUN-5K -SG01HP3-EU-AM2

SUN-6K -SG01HP3-EU-AM2

SUN-8K -SG01HP3-EU-AM2

SUN-10K -SG01HP3-EU-AM2

SUN-12K -SG01HP3-EU-AM2

SUN-15K -SG01HP3-EU-AM2

SUN-20K -SG01HP3-EU-AM2

SUN-25K -SG01HP3-EU-AM2

Battery Input Data

Battery Type

Lithium-ion

Battery Voltage Range(V)

160-700

Max.Charging Current(A)

30

30

37

50

Max.Discharging Current(A)

30

30

37

50

Charging Strategy for Li-ion Battery

Self-adaption to BMS

Number of battery input

1

PV String Input Data

Max. PV Access Power (W)

10000

12000

16000

20000

24000

30000

40000

50000

Max. PV Input Power (W)

8000

9600

12800

16000

19200

24000

32000

40000

Max. PV Input Voltage (V)

1000

Start-up Voltage（V）

180

MPPT Voltage Range（V）

150-850

Rated DC Input Voltage(V)

600

700

Max Input Short-Circuit Current（A）

30+30

39+30

39+39

Max Operating PV Input Current（A）

20+20

26+20

26+26

No.of MPP Trackers/No.of String Per MPP Tracker

2/1+1

2/2+1

2/2+2

AC Input/Output Data

Rated AC Input/Output Active Power（W）

5000

6000

8000

10000

12000

15000

20000

25000

Max AC Input/Output Apparent Power （VA）

5500

6600

8800

11000

13200

16500

22000

27500

Peak Power (off-grid)（W）

1.5 times of rated power,10s

Rated AC Input/Output Current（A）

7.6/7.3

9.1/8.7

12.2/11.6

15.2/14.5

18.2/17.4

22.8/21.8

30.4/29

37.9/36.3

Max AC Input/Output Current（A）

8.4/8

10/9.6

13.4/12.8

16.7/16

20/19.2

25/24

33.4/31.9

41.7/39.9

Max Continuous AC Passthrough (grid to load)（A）

40

80

Rated Input/Output Voltage/Range(V)

220/380V，230/400V 0.85Un-1.1Un

Grid Connection Form

3L+N+PE

Rated Input/Output Grid Frequency/Range

50Hz/45Hz-55Hz  60Hz/55Hz-65Hz

Power Factor Adjustment Range

0.8 leading to 0.8 lagging

Total Current Harmonic Distortion THDi

<3% (of nominal power)

DC Injection Current

<0.5%ln

Efficiency

Max Efficiency

97.6%

Euro Efficiency

97.0%

MPPT Efficiency

＞99%

Equipment Protection

Integrated

DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage

Protection, AC Output Short Circuit Protection, DC Component Monitoring, Arc Fault Circuit Interrupter (optional),

Anti-islanding Protection, DC Switch, Insulation Impedance Detection, Residual Current Detection

Surge Protection Level

TYPE II(DC),TYPE II(AC)

Interface

Communication Interface

RS485/RS232/CAN

Monitor Mode

GPRS/WIFI/Bluetooth/4G/LAN(optional)

LCD/LED Display

LCD

General Data

Operating Temperature Range

-40 to +60℃, >45℃ Derating

Permissible Ambient Humidity

0-100%

Permissible Altitude

2000m

Noise

≤ 55 dB(A)

Ingress Protection(IP) Rating

IP 65

Inverter Topology

Non-Isolated

Over Voltage Category

OVC II(DC),OVC III(AC)

Cabinet size（W*H*D）[mm]

408*638*237（Excluding connectors and brackets）

Weight[kg]

30.5

Warranty

5 Years/10 Years

the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy

Type Of Cooling

natural cooling

Intelligent air cooling

Grid Regulation

IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,OVE-Richtlinie R25, G98, G99, VDE-AR-N 4105

Safety EMC/Standard

IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
